Product Details: Conductor Material: Copper Standard: IS 8130:1984 Maximum Withstand Temperature: 90°C Nominal Conductor Cross-Section: 95 sq. mm Maximum Strand Diameter: 0.31 mm Maximum Conductor Resistance: 0.206 Ohms/km (at 20°C, 85% duty cycle) Core Type: Single Core Class: 6 (Superflex) Available Sizes: 6 sq. mm, 10 sq. mm, 16 sq. mm, 25 sq. mm Product Description: Backed by extensive industry experience, we offer a premium range of 95 Sq. mm Superflex Battery Cables designed for superior performance and durability. These cables are widely appreciated for their high flexibility and excellent conductivity, making them ideal for demanding battery applications. Manufactured using high-grade copper and advanced processes under the supervision of skilled professionals, these cables ensure reliability, long service life, and maximum efficiency. Strict quality control measures are followed to meet industry standards and deliver complete customer satisfaction.

Product Details: Conductor Material: Copper Core Type: Single Core Insulation Material: PVC Conductor Size Range: 6 sq. mm to 25 sq. mm Maximum Strand Diameter: 0.4 mm Maximum Conductor Resistance: 0.272 (at 20°C, 85% duty cycle) Maximum Withstand Temperature: 90°C Available Sizes: 6 sq. mm, 10 sq. mm, 16 sq. mm, 25 sq. mm Product Description: We offer premium-quality Inverter Battery Cables that are ideal for use with professional power inverters. Designed for reliable and efficient performance, these cables are available in various specifications to suit different application requirements. Key Features: Suitable for both vehicle and shop installations Equipped with battery terminal connectors and tinned contacts for easy installation Manufactured as per international standards such as ASTM, BS, and DIN High-quality copper or tinned copper conductors for superior conductivity Durable insulation options in PVC or rubber Inner sheath with rubber or double insulation for added safety Extra flexible design for convenient handling and installation Excellent resistance to oil, heat, and flame Strong electrical and mechanical performance These cables are engineered to deliver durability, safety, and consistent power transmission in inverter and battery applications.

Product Details: Material: Copper Insulation Material: PVC Nominal Conductor Cross-Section: 150 sq. mm Maximum Strand Diameter: 0.5 mm Maximum Conductor Resistance: 0.129 (at 20°C, 85% duty cycle) Maximum Withstand Temperature: 90°C Available Sizes: 6 sq. mm, 10 sq. mm, 16 sq. mm, 25 sq. mm Core Options: Single, 2, 3, 4, and 5 core Product Description: We offer high-quality Copper Battery Cables designed for efficient power transmission and long-lasting performance. These cables feature 90°C rated PVC insulation along with copper or tinned copper conductors, ensuring excellent conductivity and durability. Key Features: Available in single-core and twin-core configurations High-conductivity copper or tinned annealed copper conductors Superior insulation with low smoke and halogen-free properties Strong outer jacket made of PVC or XLPE for enhanced protection Available in multiple sheath colors such as red and black Options for different outer diameters to suit varied applications Transparent PVC jacket options available Manufactured under strict quality standards, these battery cables are suitable for a wide range of electrical and automotive applications, ensuring safety, reliability, and consistent performance

Product Details: Conductor Material: Copper Material Composition: Copper & TPV Finish: Matte Standard Length: 500 meters Pack Size: 100 meters Core Type: Single Core Temperature Rating: Up to 90°C Packaging Type: Self-wound coils / drums Diameter: 11.5 mm Insulation Material: Thermoplastic Rubber Type: Traction Battery Cable Model Number: 25 Sq. mm Conductor Resistance: 0.780 Ohms/km at 20°C Brand: Viral Cables & Wires Available Sizes: 6 sq. mm, 10 sq. mm, 16 sq. mm, 25 sq. mm Product Description: We provide high-quality Traction Battery Cables designed for reliable performance in demanding applications. These cables are manufactured with thermoplastic rubber insulation, offering excellent flexibility, durability, and resistance to varying environmental conditions. Available in convenient packaging options such as plastic reels, coils, and drums, these cables ensure ease of handling and installation. The conductors can be offered in various materials including CCA, OFC, and CCS, depending on customer requirements. Key Features: High-performance cables suitable for automotive and battery applications Durable construction with strong insulation and protective jacket Available in multiple sizes and configurations Manufactured under strict quality control standards 100% tested before dispatch Custom printing options for specifications or branding available These cables are ideal for traction battery systems and ensure long-lasting and efficient performance.

Product Details: Wire Material: Copper Conductor Material: Copper Thickness: 0.2 mm Color: Black Brand: Viral Core Type: Single Core Jacket Material: Rubber Insulation Material: Epidium Standards: IS 694/1990 Product Description: We offer high-performance Rubber MIG Welding Torch Cables designed to meet industry standards and ensure reliable operation in electric welding applications. These cables are suitable for use with welding machine connectors and deliver consistent performance even under varying temperature conditions. Manufactured using high-quality chloroprene or other flexible composite materials, these cables provide excellent durability and flexibility. The conductor is available in copper or tinned copper, ensuring efficient conductivity. The robust rubber jacket enhances protection, making the cable ideal for heavy-duty welding applications.

Conductor Material: Copper Insulation Material: PVC Maximum Withstand Temperature: 90°C Nominal Conductor Cross-Section: 4 sq. mm Maximum Strand Diameter: 0.3 mm Maximum Conductor Resistance: 4.95 (at 20°C, 85% duty cycle) Available Sizes: 6 sq. mm, 10 sq. mm, 16 sq. mm, 25 sq. mm Number of Cores: Single, 2, 3, 4, and 5 core options Product Description: Backed by extensive industry experience and expertise, we offer a wide range of high-quality Solar Battery Cables. These cables are well-regarded for their durability and reliable performance. Manufactured using premium-grade materials and advanced techniques under the supervision of skilled professionals, our products are designed to meet the highest standards of quality and ensure maximum customer satisfaction.

Number of Cores 2 Core Conductor Material Copper Min Voltage 2 kV Max Voltage 100 kV Type High Voltage Insulation Material PVC Aircraft Ignition Cable can be offered in various construction & specifications as required by customer needs. Features: High voltage cables Customized cables as per need Application: Used in aircraft engine for ignition system. Can be offered for all kinds of Ignition Applications.

Number of Cores 1 Core Conductor Material Copper Insulation Material PVC Min Voltage 2 kV Max Voltage 100 kV Type High Voltage We at viral electronics manufacture High Voltage Cable to use as test leads for the automatic capacitance test and tan delta test sets. Features: High voltage cables Customized cables as per need

We are a leading company engaged in offering a wide range of PVC insulated Multi Core Flexible Cables. These are having a wide range of application in machine tools, appliances, control panels, machinery and industries of every nature. PVC insulated multi-core sheathed cables are manufactured as per IS 694/1990, in sizes from 0.5 sq.mm. to 240 sq. mm in single core and in sizes 0.5 sq.mm. to 4 sq.mm. upto 5 cores. These sizes carry ISI mark. The rest of the sizes also generally conform to IS: 694/1990.Where the number of cores exceeds 5, two adjacent cores are blue for reference and yellow for direction in each layer. The remaining cores in each layer are Grey. On specific request, number printing on cores can also be provided. The data and information given herein are purely as a guide. VIRAL takes no responsibility for any damages arising out of incorrect use. Following are some detail information of cables: Conductors: The conductors are drawn from bright electrolytic grade copper and annealed conductors are bunched together Insulation: Bunched conductors are insulated with specially formulated, in-house developed PVC compound with high insulation resistance values Sheath: In case of multi-core cables, the insulated cores are laid up to form the core assembly. The inner cores are coded for ease of identification as per National/International coding practices. The sheathing is provided with specially formulated PVC compound to facilitate not only ease in stripping but also to withstand mechanical abrasion while in use Quality Control: Rigid tests and checks at every stage, from raw material through manufacturing stages and finally upto the finished product ensure that the cables meet National / International standards, and consumer approval

Impedance 50 Ohms Insulation Material PE, PVC Color GREY/ BLACK Material Copper Type TRIAXIAL CABLES Brand VIRAL CABLES & WIRE Number of Core 1, 3, 2 Length 500 METERS Power/Voltage LOW VOLTAGE Cable Conductor And Alloys Packaging Type Rolls Cable Jacket Polyolefins Application Used as a Probe for Nuclear Leakage Measuring Detecting Instrument Diameter 0.2 mm Triaxial cable, often referred to as triax for short, is a type of electrical cable similar to coaxial cable, but with the addition of an extra layer of insulation and a second conducting sheath. It provides greater bandwidth and rejection of interference than coax, but is more expensive.

Conductor Material Copper Material Copper Number of Core 3, 5, Single, 4, 2 Brand Viral Color Black Armored GI Sheet Rated Voltage 450 / 750V Sheath Material PVC or Flame-Retardant PVC Instrumentation Cables offered comprises flame retardant control cables that perfectly support the requirements of instrumentation control. Features: Copper conductor coming with PVC insulated and sheathed finish Product coming backed by CE and other industry certifications Details: High quality construction finish Conductor support comprising stranded copper conductor with insulation support of PVC material Sheath options of PVC or flame-retardant PVC Insulation color as per standards Suitable for use in measuring controlling/regulation for assembly and production line Available as per standards as BS, DIN and others

Number of Cores Multi Cores Number of Core 4, 5, Single, 3, 2 Power/Voltage 650/110 volts Packaging Type Rolls Conductor Type Copper Sheath Type PVC Min Nominal Size 0.05 sq.mm Max Nominal Size 120 sq.mm With vast experience and knowledge we are involved in offering an extensive range of Special Purpose Cables. These are highly reckoned among our clients due to their superior quality. Offered cables are manufactured using best quality ingredients under the supervision of highly skilled professionals to render maximum client satisfaction.
